1. 0445110290 Injection’s Basic Information

Title	China made new high quality diesel injection 0445110290 fuel injection CRI1-13
SKU 1	G1W2445110290
SKU 2	DGH130445110290

2. 0445110290 Injection’s Common Part Number

  (1)  Injection’s Exchange Information

Injection Part Number	Re-manufactured Part Number
0445110290	0 986 435 174
0 445 110 126

 (2)  Injection’s Application Information

Injector Part Number	HYUNDAI Car Model	KIA
0445110290	33800 27900	33800279002Y
	33800 21900
0 445 110 126	33800 27900
	33800 27000
	33800 279002Y
0 986 435 174	33800 21900	33800279002Y
	33800 27900



3. 0445110290 Injection’s Quality Control

（1）Injection Testing

All injection spare parts are tested for electrical characteristics, accuracy, high temperature, low temperature, withstand voltage, leakage, durability, and various working conditions.

（2）Injection Assembling

And the quality control of the injection production and installation process, our company strictly follows the standard product installation data and product installation steps to install, such as injection stroke test, injection solenoid valve tightening torque, injection nozzle tightening torque,

（3）Injection Inspection

The factory inspection of the injection is undergone full inspection, random inspection, and batch inspection three inspections. Different brands of test benches are used to test the same fuel injection for a total of no less than three times for factory inspection, and the fuel injection installation testing environment are progressed in dust-free workshop.



4. Injection’s Customized Service Requirements：

The purchased of customized injection are not less than 10 pieces.

Customized injection packages no less than 1000 pieces.

Customized products involve the need of specify logo, the OEM manufacturer needs to provide trademark authorization and the sample of logo image file.

Once the customized fuel injection is sold, it cannot be returned or exchanged if there is no quality problems.



5. 0445110290 Injection’s Warranty Instructions

（1） Product Warranty Conditions and Instructions

It is necessary to provide pictures, videos, or test reports detected by the injection inspection equipment when the injection is abnormal during use as evidence to feed back to the salesman.

Abnormal conditions are properly explained such as：1.Smoke, 2. Engine shake, 3. Difficulty starting the engine, 4. Engine noise, 5. oil leakage etc.

（2） Injection Warranty Coverage

Within 15 days after customer receives the 0445110290 injection, if there is a performance failure and the product has no appearance damage, customer can choose to replace it or repair it;

If the 0445110290 injection has performance problems during the warranty period (3 months), and it is confirmed that it is product’s problems after testing, you can contact our salesmen to replace the same model or a reworked product with the same performance for free;

If the injection house has obvious scratches, it can only be repaired and it will be returned as it is if the product is confirmed to be fault-free.

• Tips：For products not covered by warranty, our company can provide paid maintenance services. For products after paid repaired, the same performance problem will have a free warranty period within 3 months from the date of repair

（3） Injection Out of Warranty Coverage

The warranty period has expired.

Injection failure caused by high temperature, high pressure, humidity, rain and snow, saline-alkali land, earthquake, and used in abnormal environment.

Customer disassembles or repairs the injection personally resulting in damage to the injection.

Injection damage caused by man-made reasons (throwing, strong magnetic field magnetization, set fire).

Injection failure or injection damage caused by non-injection design, technology, manufacturing, quality and other issues.

Injection failure due to system pressure exceeding system approved pressure.

Injection failure caused by system voltage exceeding approved voltage.

Injection failure caused by impurities (water, lead, aluminum powder, iron powder, sulfide) in the system fuel exceeding the standard requirements.

Injection failure caused by not installing according to the tightening torque specified in the vehicle engine maintenance manual (the tightening torque is too large or too small).

Injection failure caused by not following the installation angle specified in the vehicle engine maintenance manual.

Injection failure caused by not following the cleaning requirements specified in the vehicle engine maintenance manual.

Injection failure caused by failure to replace consumable parts as specified in the vehicle engine maintenance manual.

Injection failure caused by not complying with the intake system fit clearance and exhaust system fit clearance requirements specified in the vehicle engine maintenance manual.

Failure to replace the consumable parts and the fitting clearance of the oil inlet system pipeline and the fuel injection connection in accordance with the fuel intake system specified in the vehicle engine maintenance manual.



6. 0445110290 Injection’s Causes of Damage

（1）Didn’t operate properly according to engine maintenance manual during disassembly or installation, resulting in damage to the injection .

（2）The fuel oil used for the vehicle does not meet the standard cause damage to the injection, such as: the water content in the fuel oil exceeds the standard, iron powder, aluminum powder, sulfide impurities exceed the standard, etc.

（3）The engine is not regularly maintained according to the engine maintenance manual (please refer to the vehicle maintenance manual for the maintenance mileage). For example, failure to replace the lubricating oil of the engine system for a long time will cause abnormal wear of the engine, excessive exhaust gas volume or a large amount of carbon deposits inside the engine. The filter is not replaced during maintenance or the replaced filter cannot reach the original filter standard. all above reasons can cause damage to the injection.

（4）The abrasion of the oil pump produces iron powder and aluminum powder enter the fuel injection and cause damage to the fuel injection.

（5）The deformation and abrasion of fuel tank result in iron powder or aluminum powder entering the fuel injection and causing damage to the fuel injection.

（6）The fuel injection is damaged due to replacement or adjustment of the relevant parts of the fuel injection. For example, the valve clearance does not meet the standard after the engine is repaired, the replacement or modification of the wiring harness connected to the injection fails to meet the original standard.

（7）The engine is overheated and overloaded for a long time working results in damage to the fuel injection.

（8）The injection will be damaged naturally at the end of its working life.

（9）The injection is magnetized (injection parts’ magnetic exceeded) causing the injection to not work properly.

• Before replacing the fuel injection, please check the engine parts carefully according to the engine maintenance manual to avoid the fuel injection being damaged again after replacement.



7. 0445110290 Injection’s Reasons for Not Working Normally

（1）There is air in the oil circuit of the engine fuel system.

（2）Vehicle oil pump oil supply system is not normal.

（3）Engine common rail system oil leakage or pressure limiting valve damage.

（4）There is a short circuit, cutting out and poor contact in the wiring harness connected to the fuel injection of the vehicle.

（5）The long-term placement of the injection causes the anti-rust oil to solidify, and the internal components are stuck or the oil holes are blocked.

• Before installing, carefully check whether other components in the common rail system except the fuel injection are damaged so as to prevent the fuel injection from not working properly after being replaced.



8. 0445110290 Injection’s Storage Standard

（1）Choose a suitable storage place

The warehouse and cargo yard where the fuel injection is stored should be kept clean and dry, and away from the factory buildings that generate harmful gases and dust; do not mix with acids, alkalis, salts and other substances; the storage place should have a good drainage system; the cargo yard should be flattened with gravel or furnace ash etc. to enhance the water permeability of the surface layer to keep the reservoir area dry.

（2）Strict requirements of warehousing

Strict inspections should be carried out when the fuel injections are put into storage, the surface cleaning work should be done well to remove water traces, oil stains, ash and other dirt, remove the rust and do anti-rust treatment in time. Packaged injections must be protected from damage.

（3）Keep the warehouse dry and preventing moisture

The relative humidity is usually below 70% for the fuel injections placed in the room, and the corrosion of the fuel injections is significantly reduced.

Injections must be stored in the warehouse, and they are forbidden to store in the same warehouse with commodities with high water content.

（4）Stack Properly

After the injection is exposed to rain, the corrosion rate will increase significantly. The purpose of sealing is to isolate the injection from rainwater and humid air, so the warehouse window should be checked in time to avoid rainwater entering the warehouse

If the fuel injection package is damaged, it should be repaired or replaced; when the package is damp, the packaging material should be dried; if the original anti-corrosion and oil applied at the factory is found to be damaged or dried up, it should be cleaned and re-applied oil in time.

• It is forbidden to leave the injection exposed in the air for a long time.
• It is forbidden to store acids, alkalis, salts and other substances together with the
• The unpacked fuel injection must be rust-proof during secondary storage.



9. 0445110290 Injection’s Packing

Domestic express packaging： Usually wrapped in waterproof scotch tape, such as picture No.1.

International express packaging： Wrapped with waterproof yellow tape After wrapping the black protective film, such as picture No. 2.

Pallet Shipping：Use fumigation free and recycling trays that meet export requirements, and use white wrapping protective film to wrap and bind with cable ties for the outside, such as picture No. 3,

also, the products can be packaged according to customers’ requirements.

• The packing tray is made of plastic and can be recycled.
• Transparent tape, yellow tape, black wrapping protective film, white wrapping protective film are non-degradable materials, please dispose of them properly.
• Minors are prohibited from using transparent tape, yellow tape, black wrapping protective film, and white wrapping protective film to avoid personal injury.



Domestic express packaging：Wrapped with Transparent tape	International express packaging：Wrapped with yellow tape after wrapping with black protective film	Pallet Shipping：Use pallet that meet export requirements, and use white wrapping protective film to wrap and bind with cable ties
